High Pressure Hydraulic Swing Clamp Premium Carbon Steel Surface is Hard Membrane Treated Bottom Flange Mounting

FEATURES:

1. Clamping arm swings right or left ,then clamping under on a straight line to hold the workpiece.
2. Standard angle 90 degrees,available angle 30,45,60 degrees.
3. The cylinder body material is carbon steel,the surface is hard membrane treated.
4. A flow control valve is recommeded
5. Due to their small size, these Swing Clamps do not have overload protection; therefore, the swing motion must not be restricted in any way. Be sure to adjust the contact bolt so that the clamp completes its full swing stroke and starts its clamping stroke before contacting the workpiece.
6. When clamp and unclamp the workpiece,it is necessary to use an air gun to clean the piston and the seal for removing iron slag or junk to prevent the junk from entering into the seal to cause oil leakage.
Max. operating pressure: 210 kgf/cm2

Min. operating pressure: 70 kgf/cm2

Single acting and double acting

       Dongguan Jiazheng Hydraulic Technology Co, LTD is affiliated with Taiwan Jiayan Hydraulic Technology Developing Co., LTD. which has specialized in manufacturing engineering hydraulic cylinders for more than twenty years. In order to explore the China Mainland market to meet the customers' needs with premium services, Taiwan Jiayan has set up her branch company Dongguan Jiazheng Hydraulic Technology Co, LTD in Dongguan City to engage in the research, manufacturing and sales of hydraulic clamps, pneumatic clamps and toggle clamps.

      Based on Taiwan Jiayan Hydraulic Technology's rich experience in manufacturing hydraulic products and excellent research team, Dongguan Jiazheng engages in the manufacturing and research of hydraulic and pneumatic clamps from high starting point and obtains many crucial patents on swing clamps. Jiazheng has built a whole set of scientific, complete and strict management system in the fields of raw material sourcing, production process control and after-sales service. All critical parts are imported from overseas top companies to guarantee the superior performance of the products. Before rolling off the production lines, every product must be tested on the advanced test equipment with enough test duration by strict standards and processes to guarantee the perfect quality.

       The enterprise spirit of Dongguan Jiazheng is sincerity, responsibility, enthusiasm and practicability. Enterprise tenet is that innovation is our priority and quality is life. We provide diverse services and products to customers with professional and profound technology.

       The products of our company are widely used in the industries such as vehicle, airplane, motorcycle and mould manufacturing and have won good reputation from the customers at home and abroad. Products have been sold to USA, Germany, Indian, Russian and the Southeast Asia. Except the regular clamps, Jiazheng can customize the optimized products according to customers' requirements

Enterprise Mission: Create Values for Customers Continuously

Enterprise Spirit: Sincerity, Responsibility, Enthusiasm and Pragmatism
