Pneumatic Swing Pull Clamps Alluminium Alloy Rotary Clamp Cylinder

Swing Clamp Features:

Swing motion available in 0, 45, 60, and 90 degrees
Two styles of arms
Double-locked arm design is bolted to piston shaft and around shaft diameter for extra rigidity
Flanged body

Quick swing-and-clamp movement
Uniquely adaptable for welding and assembly operations

Clamping force in direct proportion to bore size and inlet pressure non-locking

Swing Clamp Specification:

Stroke (mm) :26.7
Stroke (in) :1.050
Cylinder Bore (mm) :25
Cylinder Bore (in) 0.98
Clamping Force @ 5Bar[72Psi] (N): 20
Clamping Force @ 5Bar[72Psi] (lbf.) :50
Mount :Flanged Body
Swing Direction :LH
Air Port size :10-32
Air Consumption (per double stroke at 5 bar) (dm³) :0.130
Air Consumption (per double stroke at 7 psi) (in³): 0.005
Stroke during rotation (mm) :13.7
Stroke during rotation (in) :0.54
Vertical clamp stroke (mm) :13.0
Vertical clamp stroke (in): 0.51
Sensor Ready: No
Weight (kg) :0.25
Weight (lb) :0.56
Product Series Description :Swing Clamp
