Pneumatic Air Swing Clamp Cylinder 0°- 90° Rotating Angle
Fabco-Air type ASC double acting Pneumatic air Swing clamping
cylinder Bore size 25mm-63mm e.g. ASC-25-S-L-90 with 90°Rotating
Angle e.g ASC-25S-L-90
Product Features:
1.Fabco-air type ASC pneumatic air swing clamping cylinder
2.The product is ideal for mass production on a special purpose
machine and jig on machining center. It will greatly upgrade
production efficiency
3. When the air cylinder actuate, and the piston moves downward,
the clamping arm will swing to a rated angle, Then it lowers until
the workpiece is clamped securely.
4. To avoid too fast motion a flow control valve is suggested to
connect to the air inlet ports (A, B) on the swing clamp cylinder.
Do not clamp workpiece while the clamp is swinging to avoid
damaging on the cylinder barrel and internal parts.
5.When increasing length of clamping arm is required, be sure do
not exceed 1.5 times of the original length.
6.The cylinder body is manufactured from aluminum alloy. Surface is
hard membrane treated for maximum smoothness on inside surface and
long service life.
7. Double action motion pattern,Bore size 25mm,32mm,40mm,50mm,63mm
8.Various type for selectable in functional,Mounting and
connecting.
9.Rotating Angle 0°,45°,60°,90°for option
Specifications:
| ORDERING CODE |
| ASC | MF | 25 | S | L | 90 |
| ASC:Standard Air Swing Clamp Cylinder Double action | Type | Bore Size | Clamp Arm | Direction of Rotating | Angle of Rotating |
| Blank: Line piping type | 25:25mm | S:Single | L:Left | 90:90º |
| MF:Manifold with flow control type | 32:32mm |
| MS:With magnet type | 40:40mm | 45:45º |
| FA:Flange type | 50:50mm | D:Double | R:Right |
| TB:Threaded body type | 63:63mm | 60:60º |
| SPECIFICATION |
| Bore size(mm) | 25 | 32 | 40 | 50 | 63 |
| Working Fluid | Filtered compressed air |
| Pressure Endurance | 1.0MPa |
| Operating pressure | 0.1~0.7MPa |
| Action model | Double action |
| Diameter of Piston Rod(mm) | Ø14 | Ø16 | Ø16 |
| Swing Stroke(mm) | 9 | 11 | 13 |
| Clamping stroke Standard/Extended(mm) | 13 | 15/30 | 17/34 |
| Area pressurized pull (cm²) | 3.37 | 6.03 | 10.56 | 16.49 | 28.03 |
| Area pressurized push (cm²) | 4.91 | 8.04 | 12.57 | 19.63 | 31.17 |
| Theoretical Clamping force 5kg/cm² | 20 | 36 | 63 | 99 | 168 |
